| Quantity: | |
|---|---|
Yes
25 Years
72pcs
| Electrical performance parameters under STC | ||||||
| Model | DHM72T30-525/MR | DHM72T30-530/MR | DHM72T30-535/MR | DHM72T30-540/MR | DHM72T30-545/MR | DHM72T30-550/MR |
| Maximum power (W) | 525W | 530W | 535W | 540W | 545W | 550W |
| Voltage at maximum power point (VMP/V) | 41.24V | 41.53V | 41.82V | 42.12V | 42.41V | 42.71V |
| Current at maximum power point (IMP/A) | 12.73A | 12.76A | 12.79A | 12.82A | 12.85A | 12.88A |
| Open circuit voltage (VOC/V) | 49.05V | 49.20V | 49.35V | 49.51V | 49.69V | 49.88V |
| Short circuit current (ISC/A) | 13.61A | 13.68A | 13.75A | 13.82A | 13.89A | 13.97A |
| Component efficiency [%] | 20.31% | 20.51% | 20.70% | 20.89% | 21.09% | 21.28% |
| Power tolerance(W) | 0~+5 | |||||
| Standard test environment | Irradiance1000W/m², ambient temperature25ºC, spectrumAM1.5 | |||||
| Note:Due to continuous innovation,research and product upgrades,the parameters in this specification do not refer to a single component and can only be used for comparison between types . | ||||||
Dinghui New Energy Co., Ltd. was established in 2017, a photovoltaic enterprise integrating R&D, production, sales of solar products, which is committed to the overall solution of distributed photovoltaic system, providing consulting, design, construction, operation and maintenance and other overall services.
Top company's products include solar cells, solar panels, solar on/off-grid system schemes and other related application products.
With excellent product quality, our products have got ISO (International Standardization Organization), CQC (China Quality Certification), CE (Council of Europe) and other international certifications and have been exported to many countries and regions
| Electrical performance parameters under STC | ||||||
| Model | DHM72T30-525/MR | DHM72T30-530/MR | DHM72T30-535/MR | DHM72T30-540/MR | DHM72T30-545/MR | DHM72T30-550/MR |
| Maximum power (W) | 525W | 530W | 535W | 540W | 545W | 550W |
| Voltage at maximum power point (VMP/V) | 41.24V | 41.53V | 41.82V | 42.12V | 42.41V | 42.71V |
| Current at maximum power point (IMP/A) | 12.73A | 12.76A | 12.79A | 12.82A | 12.85A | 12.88A |
| Open circuit voltage (VOC/V) | 49.05V | 49.20V | 49.35V | 49.51V | 49.69V | 49.88V |
| Short circuit current (ISC/A) | 13.61A | 13.68A | 13.75A | 13.82A | 13.89A | 13.97A |
| Component efficiency [%] | 20.31% | 20.51% | 20.70% | 20.89% | 21.09% | 21.28% |
| Power tolerance(W) | 0~+5 | |||||
| Standard test environment | Irradiance1000W/m², ambient temperature25ºC, spectrumAM1.5 | |||||
| Note:Due to continuous innovation,research and product upgrades,the parameters in this specification do not refer to a single component and can only be used for comparison between types . | ||||||
Dinghui New Energy Co., Ltd. was established in 2017, a photovoltaic enterprise integrating R&D, production, sales of solar products, which is committed to the overall solution of distributed photovoltaic system, providing consulting, design, construction, operation and maintenance and other overall services.
Top company's products include solar cells, solar panels, solar on/off-grid system schemes and other related application products.
With excellent product quality, our products have got ISO (International Standardization Organization), CQC (China Quality Certification), CE (Council of Europe) and other international certifications and have been exported to many countries and regions
